M22-2410342

Headers, Male Pins Overview

The Harwin M22-2410342 is a 6-position pin header connector from the M22 series, featuring a 2 mm pitch and dual-row configuration. It utilizes gold and tin plating on phosphor bronze contacts housed in black nylon. Designed for right-angle through-hole mounting, this board-to-board connector supports a rated current of 1 A and withstands voltages up to 500 V. The component operates within a temperature range of -40°C to +105°C.

Headers, Male Pins Feature Summary

• Right-angle through-hole mounting design for compact PCB integration
• Dual-row structure with 2 mm spacing for high-density connections
• Gold and tin contact plating ensures reliable conductivity and corrosion resistance

Headers, Male Pins Applications

• Board-to-board interconnections in electronic assemblies
• Signal routing in industrial control systems
• Data transmission links in telecommunications equipment

Headers, Male Pins Procurement Notes

Verify obsolescence status as the component is marked End-of-Life. Confirm availability of alternative distributors or remaining stock levels before finalizing procurement plans. Ensure compatibility with mating connectors regarding pitch and row configuration.

Headers, Male Pins Selection Notes

Select this part for applications requiring right-angle orientation and robust electrical performance. Verify that the PCB layout accommodates the specific footprint dimensions and that the operating environment remains within the specified thermal limits for optimal reliability.

Headers, Male Pins Part Context

This component belongs to the Harwin M22 series, which provides versatile connectivity solutions. The series includes various configurations for different mounting styles and contact counts, supporting diverse electronic design requirements across multiple industries.

Headers, Male Pins Replacement Considerations

M22-2040305 is listed as a potential replacement option. Evaluate mechanical fit and electrical specifications against original requirements before substitution.
