M22-5430605

Headers, Male Pins Overview

The M22-5430605 is a surface mount right-angle header connector manufactured by Harwin Inc. It features an 8-position configuration with a 2.00mm pitch, arranged in two rows. The connector utilizes gold-plated brass contacts and a black polyamide (PA6T) insulator rated UL94 V-0. Designed for board-to-board applications, it supports a current rating of 1.5A per contact and operates within a temperature range of -40°C to 105°C.

Headers, Male Pins Feature Summary

• Surface mount right-angle design for compact PCB integration
• Gold-plated contacts ensure reliable signal transmission
• High-temperature resistant PA6T insulation material

Headers, Male Pins Applications

• Board-to-board interconnections
• Compact electronic device assemblies
• Industrial control systems requiring high reliability

Headers, Male Pins Procurement Notes

Verify the specific pin count and row configuration against project requirements, as datasheet variations exist. Confirm surface mount orientation and soldering profile compatibility with assembly processes. Ensure environmental ratings meet operational standards for temperature and flammability.

Headers, Male Pins Selection Notes

Select this component for applications requiring robust surface mount connectivity with high thermal stability. The gold plating offers superior corrosion resistance compared to tin alternatives. Consider the right-angle form factor for space-constrained layouts where vertical clearance is limited.

Headers, Male Pins Part Context

This part belongs to the M22 series, known for its modular design and high-density capabilities. The series supports various configurations including headers, sockets, and shrouded options. The M22-5430605 specifically addresses needs for reliable, small-pitch connections in modern electronics manufacturing.

Headers, Male Pins Replacement Considerations

Compatible mating connectors include M22-6550442R and M22-7140442 from the same manufacturer family. Verify pin count and pitch alignment when substituting. Ensure mechanical fit and electrical characteristics match original specifications.
