M50-3201145

Headers, Receptacles, Female Sockets Overview

The Harwin M50-3201145 is a double-row, right-angle IDC header from the Archer M50 series. It features 22 positions with a 1.27 mm pitch and accepts 28 AWG wire. The connector utilizes phosphor bronze contacts with gold plating for reliable signal transmission. Designed for cable installation, it employs a jackscrew fixing mechanism to secure the ribbon cable. The housing is constructed from PBT material rated UL 94 V-0. Electrical ratings include 1 A current capacity and 1 kV AC voltage withstand. Operating temperatures range from -40°C to +105°C.

Headers, Receptacles, Female Sockets Feature Summary

• Right-angle IDC termination design for efficient board space utilization
• Jackscrew fixing system ensures secure mechanical retention of the ribbon cable
• Gold-plated phosphor bronze contacts provide corrosion resistance and low contact impedance

Headers, Receptacles, Female Sockets Applications

• Ribbon cable interconnections in industrial control systems
• Data acquisition modules requiring high-density connections
• Communication equipment internal wiring harnesses

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific suffix code against official Harwin documentation to confirm the exact pin count and orientation. Ensure compatibility with standard 28 AWG ribbon cables. Confirm that the jackscrew mechanism aligns with assembly tooling requirements. Check for RoHS compliance status in the latest datasheet before finalizing procurement specifications.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a right-angle connection is required to minimize profile height. The jackscrew feature is critical for applications demanding robust cable retention without soldering the cable directly. Verify that the 1.27 mm pitch matches the target PCB footprint and mating connector. Consider the operating temperature range if the environment exceeds standard commercial limits.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Archer M50 series, which offers various configurations including single-row and double-row options. The series supports both jackscrew and latching mechanisms depending on the specific model variant. It is designed for high-reliability applications where vibration resistance and stable electrical performance are prioritized over cost-sensitive solutions.

Headers, Receptacles, Female Sockets Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Direct replacement requires matching the 1.27 mm pitch, double-row configuration, and right-angle orientation. Verify mechanical dimensions and jackscrew compatibility before considering alternative manufacturers.
