M50-4803445

Headers, Male Pins Overview

The Harwin M50-4803445 is a double-row female connector from the Archer series, designed for board-to-board applications. It features a 1.27mm pitch and supports configurations ranging from 12 to 80 positions. The component utilizes surface mount technology (SMT) for secure PCB attachment. Contacts are gold-plated to ensure reliable signal transmission. The housing is constructed from black liquid crystal polymer (LCP), offering high thermal stability and UL 94 V-0 flammability rating. This connector is engineered for high-density interconnects in compact electronic assemblies.

Headers, Male Pins Feature Summary

• Double-row female socket design for high-density board-to-board connections
• Gold-plated phosphor bronze contacts for enhanced conductivity and corrosion resistance
• Black LCP housing with UL 94 V-0 rating for thermal and fire safety
• Surface mount termination style for automated assembly integration

Headers, Male Pins Applications

• High-density electronic modules requiring robust board-to-board interconnects
• Telecommunications equipment utilizing compact signal routing
• Medical devices needing reliable high-frequency data transmission
• Industrial control systems with space-constrained circuit boards

Headers, Male Pins Procurement Notes

Verify the specific position count suffix within the M50-480xx45 series code to ensure compatibility with your design requirements. Confirm that the surface mount footprint matches your PCB layout guidelines. Check RoHS compliance status and moisture sensitivity level (MSL) ratings prior to storage and reflow soldering processes to maintain component integrity.

Headers, Male Pins Selection Notes

Select this model when a double-row female connector with 1.27mm pitch is required for SMT assembly. Ensure the mating header matches the Archer series specifications for proper latch engagement. Consider the operating temperature range of -40°C to +105°C for environmental suitability. Validate that the contact material and plating meet the electrical performance needs of the application.

Headers, Male Pins Part Context

This component belongs to the Harwin Archer M50 series, a family of connectors known for their push-pull latching mechanism and high reliability. The M50 series is widely used in demanding environments where vibration resistance and secure connection are critical. The specific part number indicates a female receptacle variant within this standardized lineup.

Headers, Male Pins Replacement Considerations

M50-4802445

Headers, Male Pins FAQ

What is the mating force characteristic of this connector?

The connector utilizes a push-pull latching system designed for quick and secure mating without excessive insertion force.

Is the housing material suitable for high-temperature reflow soldering?

Yes, the black LCP housing is rated for high temperatures and meets UL 94 V-0 flammability standards, supporting standard SMT processes.
