M80-4000000F1-04-PF1-00-000

M80-4000000F1-04-PF1-00-000 is listed in the Headers, Receptacles, Female Sockets range at ChipApex. The manufacturer field lists Harwin Inc.. Its product description is 4 POS. FEMALE SIL VERTICAL THROU. Review the specifications below when checking this part for your BOM.

Headers, Receptacles, Female Sockets specifications for M80-4000000F1-04-PF1-00-000

• Description：4 POS. FEMALE SIL VERTICAL THROU
• Series：Datamate Mix-Tek
• Mfr：Harwin Inc.
• Package：Bulk
• Connector Type：Receptacle
• Contact Type：Female Socket, Power
• Style：Board to Board or Cable
• Number of Positions：4
• Number of Positions Loaded：All
• Pitch - Mating：0.157" (4.00mm)
• Number of Rows：1
• Row Spacing - Mating：-
• Mounting Type：Through Hole
• Termination：Solder
• Fastening Type：Screw Lock
• Contact Finish - Mating：Gold
• Contact Finish Thickness - Mating：-
• Insulation Color：Black
• Insulation Height：0.343" (8.71mm)
• Contact Length - Post：0.138" (3.50mm)
• Operating Temperature：-55°C ~ 150°C
• Material Flammability Rating：UL94 V-0
• Contact Finish - Post：Gold
• Mated Stacking Heights：7.3mm
• Ingress Protection：-
• Features：Jackscrews, Polarizing Key
• Current Rating (Amps)：40A
• Voltage Rating：800VAC/DC

Headers, Receptacles, Female Sockets datasheet and documents for M80-4000000F1-04-PF1-00-000
