MAL213215222E3

MAL213215222E3 is listed in the Aluminum Electrolytic Capacitors range at ChipApex. The manufacturer field lists Vishay Beyschlag/Draloric/BC Components. Its product description is CAP ALUM 2200UF 16V AXIAL TH. Review the specifications below when checking this part for your BOM.

Aluminum Electrolytic Capacitors specifications for MAL213215222E3

• Description：CAP ALUM 2200UF 16V AXIAL TH
• Series：132 ALL-DIN
• Mfr：Vishay Beyschlag/Draloric/BC Components
• Package：Bulk
• Capacitance：2200 µF
• Tolerance：-10%, +50%
• Voltage - Rated：16 V
• ESR (Equivalent Series Resistance)：110mOhm @ 100Hz
• Lifetime @ Temp.：15000 Hrs @ 85°C
• Operating Temperature：-40°C ~ 85°C
• Polarization：Polar
• Ratings：-
• Applications：General Purpose
• Ripple Current @ Low Frequency：1.3 A @ 100 Hz
• Ripple Current @ High Frequency：-
• Lead Spacing：-
• Size / Dimension：0.709" Dia x 1.496" L (18.00mm x 38.00mm)
• Height - Seated (Max)：-
• Surface Mount Land Size：-
• Mounting Type：Through Hole
• Package / Case：Axial, Can
• Impedance：-

Aluminum Electrolytic Capacitors datasheet and documents for MAL213215222E3
