MPXV5004GP

Pressure Sensors Transducers Overview

The MPXV5004GP is a piezoresistive transducer designed for measuring differential pressure in air and gas flow applications. It features a measurement range from -1 to 3.92 kPa with temperature compensation for high accuracy. The device provides an analog voltage output ranging from 1V to 4.9V, powered by a supply voltage of 4.75V to 5.25V. Housed in an 8-DIP module package with PC pin termination, it operates within a temperature range of 0°C to 85°C. This sensor is suitable for medical devices and other precision applications requiring reliable pressure sensing.

Pressure Sensors Transducers Feature Summary

• Monolithic silicon piezoresistive design integrating micro-mechanical technology
• Temperature compensated for enhanced accuracy across operating ranges
• High-level analog voltage output proportional to applied pressure
• Durable thermoplastic (PPS) encapsulation for robust performance

Pressure Sensors Transducers Applications

• Medical devices requiring precise air and gas flow measurement
• Industrial control systems monitoring differential pressure
• Consumer electronics utilizing pressure sensing capabilities
• Home appliance pressure monitoring applications

Pressure Sensors Transducers Procurement Notes

Verify the specific suffix 'GP' against official NXP documentation to confirm package type and material specifications. Ensure compatibility with existing board layouts for 8-DIP modules. Check current product status as some variants may be discontinued or replaced. Confirm temperature compensation ranges match application requirements. Validate supply voltage parameters before integration into final designs.

Pressure Sensors Transducers Selection Notes

Select this component when differential pressure measurement up to 3.92 kPa is required. Consider the 8-DIP package for through-hole mounting needs. Evaluate the analog voltage output range against interface circuitry capabilities. Assess temperature compensation requirements for the intended operating environment. Compare against similar series members for specific port or packaging variations.

Pressure Sensors Transducers Part Context

This part belongs to the MPxx5004 series of piezoresistive transducers. These sensors are designed for wide-ranging applications including automotive, industrial, and medical markets. The series utilizes state-of-the-art monolithic silicon technology. Variants differ primarily in pressure range, package configuration, and specific feature sets like auto-zeroing capabilities.
