PR27-18V-S-900-1A-E

PR27-18V-S-900-1A-E is listed in the Power Relays, Over 2 Amps range at ChipApex. The manufacturer field lists Same Sky (Formerly CUI Devices). Its product description is 32.23 X 27.4 X 27.92 MM, 18 V, 4. Review the specifications below when checking this part for your BOM.

Power Relays, Over 2 Amps specifications for PR27-18V-S-900-1A-E

• Description：32.23 X 27.4 X 27.92 MM, 18 V, 4
• Series：PR27
• Mfr：Same Sky (Formerly CUI Devices)
• Package：Box
• Mounting Type：Through Hole
• Coil Voltage：18VDC
• Contact Form：SPST-NO (1 Form A)
• Contact Rating (Current)：40 A
• Switching Voltage：300VAC, 30VDC - Max
• Load - Max Switching：10000VA, 900W
• Coil Current：47.4 mA
• Coil Type：Non Latching
• Features：-
• Termination Style：PC Pin, Quick Connect - 0.250" (6.3mm)
• Seal Rating：Sealed - Fully
• Coil Insulation：Class B
• Must Operate Voltage：13.5 VDC
• Must Release Voltage：1.8 VDC
• Operating Temperature：-55°C ~ 85°C
• Contact Material：Silver Tin Oxide (AgSnO)
• Approval Agency：cURus
• Relay Type：General Purpose
• Grade：-
• Qualification：-
• Operate Time：15 ms
• Release Time：10 ms

Power Relays, Over 2 Amps datasheet and documents for PR27-18V-S-900-1A-E
