R10-E1Y4-V700

R10-E1Y4-V700 is listed in the Power Relays, Over 2 Amps range at ChipApex. The manufacturer field lists TE Connectivity Potter & Brumfield Relays. Its product description is RELAY GEN PURPOSE 4PDT 3A 24V. Review the specifications below when checking this part for your BOM.

Power Relays, Over 2 Amps specifications for R10-E1Y4-V700

• Description：RELAY GEN PURPOSE 4PDT 3A 24V
• Series：R10
• Mfr：TE Connectivity Potter & Brumfield Relays
• Package：Bulk
• Mounting Type：Socketable
• Coil Voltage：24VDC
• Contact Form：4PDT (4 Form C)
• Contact Rating (Current)：3:00 AM
• Switching Voltage：120VAC - Nom
• Load - Max Switching：-
• Coil Current：34.3 mA
• Coil Type：Non Latching
• Features：-
• Termination Style：Plug In
• Seal Rating：-
• Coil Insulation：-
• Must Operate Voltage：18 VDC
• Must Release Voltage：-
• Operating Temperature：-55°C ~ 75°C
• Contact Material：Silver (Ag)
• Approval Agency：CSA, UR
• Relay Type：General Purpose
• Grade：-
• Qualification：-
• Operate Time：-
• Release Time：-

Power Relays, Over 2 Amps datasheet and documents for R10-E1Y4-V700

Explore related parts through Relays, all product categories, ChipApex homepage.
