S9S12P32J0CFTR

$3.03

Description：IC MCU 16BIT 32KB FLASH 48QFN
Series：HCS12
Mfr：NXP USA Inc.
Package：Tape & Reel (TR)
Core Processor：HCS12

SKU:0e35f24ac89b Category: Microcontrollers Brand: NXP USA Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

S9S12P32J0CFTR is listed in the Microcontrollers range at ChipApex. The manufacturer field lists NXP USA Inc.. Its product description is IC MCU 16BIT 32KB FLASH 48QFN. Review the specifications below when checking this part for your BOM.

Microcontrollers specifications for S9S12P32J0CFTR

Description：IC MCU 16BIT 32KB FLASH 48QFN
Series：HCS12
Mfr：NXP USA Inc.
Package：Tape & Reel (TR)
Core Processor：HCS12
Core Size：16-Bit
Speed：32MHz
Connectivity：CANbus, SCI, SPI
Peripherals：LVD, POR, PWM, WDT
Number of I/O：34
Program Memory Size：32KB (32K x 8)
Program Memory Type：FLASH
EEPROM Size：4K x 8
RAM Size：2K x 8
Voltage - Supply (Vcc/Vdd)：1.72V ~ 5.5V
Data Converters：A/D 10x12b
Oscillator Type：Internal
Operating Temperature：-40°C ~ 85°C (TA)
Mounting Type：Surface Mount
Supplier Device Package：48-QFN-EP (7x7)
Package / Case：48-TFQFN Exposed Pad

Microcontrollers datasheet and documents for S9S12P32J0CFTR

S9S12P32J0CFTR

Microcontrollers Overview

The S9S12P32J0CFTR is a 16-bit microcontroller from the NXP S12P series, built on the HCS12 core. It features 32 kB of Flash program memory and 2 kB of RAM. The device operates at a maximum clock frequency of 32 MHz within an operating temperature range of -40°C to +85°C. It is housed in a QFN-48 package and supports AEC-Q100 automotive qualification. Key peripherals include a 12-bit ADC with 10 channels, eight timers, and interfaces such as CAN, SCI, and SPI. The supply voltage ranges from 3.15 V to 5.5 V.

Microcontrollers Feature Summary

Automotive qualified under AEC-Q100 standards for reliability
Integrated 12-bit analog-to-digital converter with multiple channels
Supports Controller Area Network (CAN) communication protocol
Includes eight timer/counters for precise timing control

Microcontrollers Applications

Automotive electronic control units
Body electronics systems
Powertrain management modules
Chassis control applications

Microcontrollers Procurement Notes

Verify the specific suffix CFTR indicates tape and reel packaging when ordering. Confirm the AEC-Q100 qualification status aligns with target automotive requirements. Ensure the QFN-48 package dimensions match the PCB footprint design. Check for moisture sensitivity level compliance during storage and handling procedures.

Microcontrollers Selection Notes

Select this component for designs requiring automotive-grade reliability with moderate processing power. The 32 MHz speed and 32 kB Flash suit complex control logic without excessive resource usage. Compare against other S12P variants if higher memory or different pin counts are needed. Consider the QFN-48 thermal performance for enclosed environments.

Microcontrollers Part Context

This part belongs to the NXP S12P family of 16-bit microcontrollers designed for automotive applications. The series emphasizes robustness and integrated connectivity options like CAN. The S9S12P32 variant offers a balance of performance and cost for body and chassis electronics.
