TG5032SFN 20.0000M-CAGNDAB

Oscillators Overview

The TG5032SFN 20.0000M-CAGNDAB is a Voltage-Controlled Temperature Compensated Crystal Oscillator (VCTCXO) manufactured by Epson. It operates at a nominal frequency of 20 MHz with a stability of ±100 ppb. The device utilizes a 3.3 V supply and delivers a clipped sine wave output signal. It is housed in a compact 4-SMD, No Lead package suitable for surface mount applications. The operational temperature range spans from -40°C to +85°C, ensuring reliability across various industrial environments.

Oscillators Feature Summary

• High frequency stability of ±100 ppb
• Voltage-controlled temperature compensation
• Compact 4-SMD no-lead package design

Oscillators Applications

• Wireless communication systems
• Portable electronic devices
• Industrial control equipment

Oscillators Procurement Notes

Verify the specific suffix CAGNDAB against official Epson documentation to confirm pinout and electrical characteristics. Ensure compatibility with 3.3 V logic levels and clipped sine wave requirements. Confirm that the ±100 ppb stability meets system timing constraints. Check thermal management needs for the -40°C to +85°C operating range.

Oscillators Selection Notes

Select this component when high stability is required within a small footprint. The voltage control feature allows for frequency tuning. The clipped sine wave output is suitable for CMOS-compatible inputs. Consider the 3.3 V supply constraint and current consumption limits during design integration.

Oscillators Part Context

This model belongs to the TG5032SFN series of ultra-high stability oscillators. The series offers various frequency options and packaging configurations. The specific part number indicates a 20 MHz frequency and a particular stability grade. Epson designs these components for precision timing applications requiring low phase noise.

Oscillators Replacement Considerations

Direct substitutes include other TG5032SFN variants with matching frequency and stability. Verify pin compatibility and output waveform before substitution. Cross-reference with Epson's official replacement guide for equivalent performance.
