IXD2142B30DER-G

Voltage Regulators - DC DC Switching Regulators Overview

The IXD2142B30DER-G is a step-up DC-DC converter manufactured by Zilog, classified under Switching Voltage Regulators within the PMIC category. It features an integrated load disconnect function and operates with a fixed switching frequency of 3.0 MHz. The device supports PFM/PWM auto-switching modes to optimize efficiency across varying load conditions. It provides a continuous output current capability of 0.8 A. The component is supplied in a Reel packaging format.

Voltage Regulators - DC DC Switching Regulators Feature Summary

• Integrates a load disconnect function for system power management
• Supports automatic switching between PFM and PWM modes
• Operates at a fixed 3.0 MHz switching frequency

Voltage Regulators - DC DC Switching Regulators Applications

• Portable electronic devices requiring efficient step-up conversion
• Battery-powered systems utilizing load disconnect capabilities
• Applications necessitating high-frequency switching regulators

Voltage Regulators - DC DC Switching Regulators Procurement Notes

Verify the specific manufacturer designation as ZiLOG or Zilog when sourcing this component. Confirm that the suffix DER-G corresponds to the correct package and tape-and-reel configuration. Ensure compatibility with the required 3.0 MHz operation mode and 0.8 A current rating for your design. Check for any regional sales restrictions or limited availability status before finalizing procurement plans.

Voltage Regulators - DC DC Switching Regulators Selection Notes

Select this part when a step-up converter with a built-in load disconnect feature is required. The 3.0 MHz frequency allows for smaller external passive components compared to lower-frequency alternatives. Choose this model over the IXD2141 series if automatic PFM/PWM switching is needed rather than PWM-only operation. Ensure the input voltage range matches the source supply requirements.

Voltage Regulators - DC DC Switching Regulators Part Context

This component belongs to the IXD2142 family of step-up DC-DC converters from Zilog. It shares similarities with models like the IXD2142B18CER-G but differs in switching frequency and specific functional configurations. The family generally targets portable applications requiring efficient power management and compact form factors.

Voltage Regulators - DC DC Switching Regulators Replacement Considerations

The IXD2142B33DMR-G is a related variant within the same product line. Verify if the alternative part number meets the specific 3.0 MHz frequency requirement and load disconnect functionality needs.
