MPX2202ASX

Pressure Sensors Transducers Overview

The MPX2202ASX is a surface-mount absolute pressure sensor from NXP Semiconductors, housed in a 5-pin UNIBODY package. It features on-chip temperature compensation and silicon piezoresistive technology. The device supports a maximum operating pressure of 200 kPa with a maximum overpressure rating of 400 kPa. Electrical specifications include a typical sensitivity of 0.2 mV/kPa and an output range of 0 mV to 10 V at 10 V supply. It operates within a temperature range of -40 °C to +125 °C and accepts a maximum power supply voltage of 16 V.

Pressure Sensors Transducers Feature Summary

• On-chip temperature compensation for accurate readings across varying thermal conditions
• Silicon piezoresistive sensing element providing high reliability
• UNIBODY surface-mount construction for board integration

Pressure Sensors Transducers Applications

• Board mount pressure sensing systems
• Industrial process control monitoring
• HVAC system pressure measurement

Pressure Sensors Transducers Procurement Notes

Verify the manufacturer part number against official NXP documentation to ensure authenticity. Confirm that the specific suffix matches the required pin configuration and packaging style. Check for RoHS compliance status if environmental regulations apply to your assembly. Ensure the supplier provides valid traceability records for quality assurance purposes.

Pressure Sensors Transducers Selection Notes

Select this component when a compensated absolute pressure sensor is required for surface-mount applications. The 200 kPa range suits low-pressure industrial environments. Consider the 5-pin MPAK footprint for PCB layout constraints. Verify that the analog bridge output interface aligns with the signal conditioning circuitry design requirements.

Pressure Sensors Transducers Part Context

This device belongs to the MPX series of silicon pressure sensors manufactured by NXP Semiconductors. The series utilizes piezoresistive technology integrated into a compact package. These sensors are designed for general-purpose pressure measurement tasks requiring stability and accuracy without external calibration.

Pressure Sensors Transducers Replacement Considerations

Public confirmed substitute part numbers: MPXM2102AS.
