Product Detailed Parameters
- Description：600V SENSITIVE SCR IN SOT89 PACK
- Series：SxX8BBS
- Mfr：IXYS
- Package：Tape & Reel (TR),Cut Tape (CT)
- Voltage - Off State：600 V
- Voltage - Gate Trigger (Vgt) (Max)：800 mV
- Current - Gate Trigger (Igt) (Max)：200 µA
- Current - Hold (Ih) (Max)：10 mA
- Current - Non Rep. Surge 50, 60Hz (Itsm)：10A, 12A
- SCR Type：Sensitive Gate
- Operating Temperature：-40°C ~ 125°C (TJ)
- Grade：-
- Qualification：-
- Mounting Type：Surface Mount
- Package / Case：TO-236-3, SC-59, SOT-23-3
- Supplier Device Package：SOT-23-3
- Voltage - On State (Vtm) (Max)：1.7 V
- Current - On State (It (AV)) (Max)：510 mA
- Current - On State (It (RMS)) (Max)：800 mA
- Current - Off State (Max)：5 µA
Download product information
Overview
The S6X8BBS3RP is a Silicon Controlled Rectifier (SCR) manufactured by IXYS, designed for surface-mount applications. It features a sensitive gate configuration with a maximum repetitive peak reverse voltage of 600 V and an RMS on-state current rating of 0.8 A. The device is housed in a compact SOT-89 package, which provides a three-pin configuration suitable for automated assembly processes. This component belongs to the SCR product category within the thyristor sub-classification, offering a balance of electrical performance and physical footprint for modern electronic designs.
Feature Summary
- Sensitive gate triggering mechanism allows for efficient control with low gate drive requirements.
- Surface-mount construction enables integration into space-constrained printed circuit board layouts.
- Robust blocking voltage capability ensures reliable operation in high-voltage switching environments.
Applications
- AC power control circuits requiring compact form factors
- Lighting dimmer applications utilizing surface-mount technology
- Solid-state relay inputs and motor speed control systems
Procurement Notes
Verify the specific manufacturer datasheet for the S6X8BBS3RP to confirm exact thermal characteristics and mechanical dimensions prior to finalizing the design. Ensure that the selected supplier provides authentic components from authorized distribution channels to maintain quality standards. Cross-reference the part number with official manufacturer catalogs to validate availability and lead times for production planning purposes.
Selection Notes
Select this component when a low-current SCR is required for surface-mount assembly. The 600 V rating suits general-purpose AC line applications. Compare the SOT-89 package constraints against available board space. Consider the sensitive gate特性 if the driving circuit has limited current output capacity compared to standard gate devices.
Part Context
This device is part of IXYS' portfolio of discrete thyristors, specifically targeting the consumer and industrial electronics markets where miniaturization is critical. The S6X8BBS3RP complements other surface-mount power semiconductors offered by the manufacturer, providing designers with standardized packaging options for integrating control functions directly onto main system boards without requiring through-hole mounting techniques.
Replacement Considerations
Publicly confirmed substitute part numbers are not available in the provided documentation. Designers should consult the manufacturer's official replacement guide or contact technical support for validated equivalent components that match the electrical specifications and package outline.
