Edgeboard Connectors

Card edge or edgeboard connectors are a style of connector system in which (typically) a pattern of exposed copper regions at the periphery of a printed circuit board constitutes one-half of a mating connector pair. A common use case being the connection of accessory cards such as graphics accelerators to computer motherboards in desktop PC applications, they offer a relatively low-cost, high density interconnect option for applications where durability is not a primary concern.

Screen Default Ranking Price By Date

Select products	Mfr	Description	Package	Supplier Device Package	Mounting Type	Series	Operating Temperature
305-058-500-268 $11.72	EDAC Inc.	CONN EDGE DUAL FMALE 58POS 0.156	Box		Panel Mount	305	-40°C ~ 105°C
305-058-500-278 $11.72	EDAC Inc.	CONN EDGE DUAL FMALE 58POS 0.156	Box		Panel Mount	305	-40°C ~ 105°C
305-058-500-501 $9.32	EDAC Inc.	CONN EDGE DUAL FMALE 58POS 0.156	Box		Free Hanging (In-Line)	305	-40°C ~ 105°C
305-058-500-502 $9.32	EDAC Inc.	CONN EDGE DUAL FMALE 58POS 0.156	Box		Panel Mount	305	-40°C ~ 105°C
305-058-500-503 $11.11	EDAC Inc.	CONN EDGE DUAL FMALE 58POS 0.156	Box		Panel Mount	305	-40°C ~ 105°C
305-058-500-504 $9.32	EDAC Inc.	CONN EDGE DUAL FMALE 58POS 0.156	Box		Panel Mount	305	-40°C ~ 105°C
305-058-500-507 $11.11	EDAC Inc.	CONN EDGE DUAL FMALE 58POS 0.156	Box		Panel Mount	305	-40°C ~ 105°C
305-058-500-508 $11.11	EDAC Inc.	CONN EDGE DUAL FMALE 58POS 0.156	Box		Panel Mount	305	-40°C ~ 105°C
