MLV-L01D-E1NS-N

Pressure Sensors Transducers Overview

The MLV-L01D-E1NS-N is a board-mount differential pressure sensor from the Amphenol All Sensors MLV series. It features a silicon piezoresistive sensing element with an analog output voltage ranging from 0 mV to 7 mV at 5 V supply. The device measures differential pressure within a range of -1 to +1 inch-H2O, corresponding to ±0.04 PSI or ±0.25 kPa. It utilizes a Single In-line Package (SIP) configuration with dual ports located on the same side. The component is designed for direct integration into electronic circuits requiring low-pressure differential monitoring.

Pressure Sensors Transducers Feature Summary

• Utilizes silicon piezoresistive technology for precise differential pressure measurement
• Provides linear analog voltage output proportional to applied pressure difference
• Features a compact SIP package with dual ports positioned on the same side for streamlined mounting

Pressure Sensors Transducers Applications

• Low-flow air monitoring systems
• Filter status indication in HVAC units
• Leak detection in pneumatic lines

Pressure Sensors Transducers Procurement Notes

Verify the specific suffix E1NS-N against official Amphenol documentation to confirm port orientation and pinout compatibility. Ensure the target application operates within the specified 5 V supply and pressure range. Confirm that the SIP package dimensions align with the PCB footprint requirements before finalizing procurement.

Pressure Sensors Transducers Selection Notes

Select this model when a differential pressure range of ±1 inch-H2O is required with a simple analog interface. The same-side dual-port design facilitates specific tubing arrangements. Consider the 0-7 mV output span relative to the system's ADC resolution and input impedance constraints to ensure accurate signal acquisition.

Pressure Sensors Transducers Part Context

This component belongs to the MLV series of board-mount pressure sensors manufactured by Amphenol All Sensors. The series typically offers various pressure ranges and package configurations. The MLV-L01D-E1NS-N specifically addresses low-range differential applications using a standard SIP form factor suitable for automated assembly processes.

Pressure Sensors Transducers Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Verify mechanical and electrical compatibility if considering alternative suppliers.
