SL 3 053 34 S

$1.85

Description：MALE HEADER 0.635 MM, DIMENSIO
Series：SL 3 053
Mfr：Fischer Elektronik
Package：Bulk

SKU:4f69b4bccab9 Category: Headers, Male Pins Brand: Fischer Elektronik

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

SL 3 053 34 S is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Fischer Elektronik. Its product description is MALE HEADER 0.635 MM, DIMENSIO. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for SL 3 053 34 S

Description：MALE HEADER 0.635 MM, DIMENSIO
Series：SL 3 053
Mfr：Fischer Elektronik
Package：Bulk
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：34
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Unshrouded
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.228" (5.80mm)
Contact Length - Post：0.213" (5.40mm)
Overall Contact Length：-
Insulation Height：0.110" (2.80mm)
Contact Shape：Square
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：157.5µin (4.00µm)
Contact Finish - Post：Tin
Contact Material：Copper Tin
Insulation Material：Polyamide (PA46), Nylon 4/6, Glass Filled
Features：-
Operating Temperature：-40°C ~ 163°C
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：3A
Voltage Rating：250VAC

Headers, Male Pins datasheet and documents for SL 3 053 34 S

SL 3 053 34 S

Headers, Male Pins Overview

The SL 3 053 34 S is a male header connector manufactured by Fischer Elektronik. It features a single row with 34 positions and a contact pitch of 0.635 mm (25.1 mil). The connector utilizes through-hole termination for PCB mounting. Contacts are tin-plated to ensure reliable electrical performance. The component is designed for secure board-to-board or cable connections in electronic assemblies.

Headers, Male Pins Feature Summary

Precision-engineered male header design ensuring stable mechanical connection
Tin-plated contact surface for corrosion resistance and conductivity
Single-row configuration optimized for compact circuit board layouts

Headers, Male Pins Applications

General-purpose electronic equipment interconnects
Industrial control system signal routing
Consumer electronics assembly boards

Headers, Male Pins Procurement Notes

Verify the specific pin count matches the '34' designation in the model number. Confirm the 0.635 mm pitch requirement against your PCB footprint. Ensure the tin-plated finish aligns with your soldering process compatibility. Check RoHS compliance status if required by your manufacturing standards. Validate that the through-hole mounting style fits your assembly capabilities.

Headers, Male Pins Selection Notes

Select this part when a fine-pitch 0.635 mm male header is required. Choose the tin-plated variant for standard cost-effective applications. Consider the single-row format for space-constrained designs. Verify that the 34-position count meets your circuit interface needs. Ensure the through-hole technology suits your production line.

Headers, Male Pins Part Context

This component belongs to the SL 3 053 series from Fischer Elektronik. The series is characterized by precision engineering and fine pitch spacing. It serves as a reliable interconnect solution for various electronic applications. The specific model denotes the position count and contact plating type within the product family.
