Edgeboard Connectors

Card edge or edgeboard connectors are a style of connector system in which (typically) a pattern of exposed copper regions at the periphery of a printed circuit board constitutes one-half of a mating connector pair. A common use case being the connection of accessory cards such as graphics accelerators to computer motherboards in desktop PC applications, they offer a relatively low-cost, high density interconnect option for applications where durability is not a primary concern.

Screen Default Ranking Price By Date

Select products	Mfr	Description	Package	Supplier Device Package	Mounting Type	Series	Operating Temperature
305-082-500-512 $12.40	EDAC Inc.	CONN EDGE DUAL FMALE 82POS 0.156	Bulk		Panel Mount	305	-40°C ~ 105°C
305-082-500-558 $13.67	EDAC Inc.	CONN EDGE DUAL FMALE 82POS 0.156	Box		Panel Mount	305	-40°C ~ 105°C
305-082-500-568 $13.67	EDAC Inc.	CONN EDGE DUAL FMALE 82POS 0.156	Box		Panel Mount	305	-40°C ~ 105°C
305-082-500-578 $13.67	EDAC Inc.	CONN EDGE DUAL FMALE 82POS 0.156	Box		Panel Mount	305	-40°C ~ 105°C
305-082-520-201 $11.30	EDAC Inc.	CONN EDGE DUAL FMALE 82POS 0.156	Box		Through Hole	305	-40°C ~ 105°C
305-082-520-202 $11.30	EDAC Inc.	CONN EDGE DUAL FMALE 82POS 0.156	Box		Panel Mount, Through Hole	305	-40°C ~ 105°C
305-082-520-203 $13.06	EDAC Inc.	CONN EDGE DUAL FMALE 82POS 0.156	Box		Panel Mount, Through Hole	305	-40°C ~ 105°C
305-082-520-204 $11.30	EDAC Inc.	CONN EDGE DUAL FMALE 82POS 0.156	Box		Panel Mount, Through Hole	305	-40°C ~ 105°C
