Edgeboard Connectors

Card edge or edgeboard connectors are a style of connector system in which (typically) a pattern of exposed copper regions at the periphery of a printed circuit board constitutes one-half of a mating connector pair. A common use case being the connection of accessory cards such as graphics accelerators to computer motherboards in desktop PC applications, they offer a relatively low-cost, high density interconnect option for applications where durability is not a primary concern.

Screen Default Ranking Price By Date

Select products	Mfr	Description	Package	Supplier Device Package	Mounting Type	Series	Operating Temperature
1761786-1 $7.24	TE Connectivity AMP Connectors	CONN EDGE DUAL FMALE 20POS GOLD	Bulk,Tray		Through Hole	Standard Edge II	-55°C ~ 85°C
1761842-1 $6.71	TE Connectivity AMP Connectors	CONN PCI CARDEDGE FML 120P 0.050	Bulk		Surface Mount	Standard Edge .050	-
1761879-1 $7.48	TE Connectivity AMP Connectors	CONN EDGE DUAL FMALE 30POS GOLD	Tray		Board Edge, Straddle Mount	Standard Edge II	-55°C ~ 85°C
1766200-1 $5.64	TE Connectivity AMP Connectors	CONN FEMALE GOLD	Tray,Tray		Board Edge, Straddle Mount	Crown Edge, Elcon	-
1766308-1 $13.50	TE Connectivity AMP Connectors	CONN VRM FMALE 44POS GOLD	Tray		Through Hole	Mini Crown Edge, Elcon	-55°C ~ 105°C
1766336-1 $13.92	TE Connectivity AMP Connectors	CONN VRM FMALE 30POS GOLD	Tray		Surface Mount	Mini Crown Edge, Elcon	-55°C ~ 105°C
1766354-1 $7.97	TE Connectivity AMP Connectors	CONN EDGE DUAL FMALE 4POS 0.098	Bulk		Through Hole	-	-
1766355-1 $3.71	TE Connectivity AMP Connectors	CONN EDGE DUAL FMALE 8POS GOLD	Bulk		Through Hole	-	-55°C ~ 105°C
