Edgeboard Connectors

Card edge or edgeboard connectors are a style of connector system in which (typically) a pattern of exposed copper regions at the periphery of a printed circuit board constitutes one-half of a mating connector pair. A common use case being the connection of accessory cards such as graphics accelerators to computer motherboards in desktop PC applications, they offer a relatively low-cost, high density interconnect option for applications where durability is not a primary concern.

Screen Default Ranking Price By Date

Select products	Mfr	Description	Package	Supplier Device Package	Mounting Type	Series	Operating Temperature
305-014-556-512 $7.86	EDAC Inc.	CONN EDGE DUAL FMALE 14POS 0.156	Bulk		Board Edge, Straddle Mount	305	-40°C ~ 105°C
305-014-556-558 $9.19	EDAC Inc.	CONN EDGE DUAL FMALE 14POS 0.156	Box		Board Edge, Straddle Mount	305	-40°C ~ 105°C
305-014-556-568 $9.19	EDAC Inc.	CONN EDGE DUAL FMALE 14POS 0.156	Box		Board Edge, Straddle Mount	305	-40°C ~ 105°C
305-014-556-578 $9.19	EDAC Inc.	CONN EDGE DUAL FMALE 14POS 0.156	Box		Board Edge, Straddle Mount	305	-40°C ~ 105°C
305-016-500-201 $3.15	EDAC Inc.	CONN CARDEDGE 16POS .156 X .140	Bulk		Surface Mount	305	-40°C ~ 105°C
305-016-500-202 $4.97	EDAC Inc.	CONN EDGE DUAL FMALE 16POS 0.156	Box		Panel Mount	305	-40°C ~ 105°C
305-016-500-203 $6.85	EDAC Inc.	CONN EDGE DUAL FMALE 16POS 0.156	Box		Panel Mount	305	-40°C ~ 105°C
305-016-500-204 $4.97	EDAC Inc.	CONN EDGE DUAL FMALE 16POS 0.156	Box		Panel Mount	305	-40°C ~ 105°C
