Edgeboard Connectors

Card edge or edgeboard connectors are a style of connector system in which (typically) a pattern of exposed copper regions at the periphery of a printed circuit board constitutes one-half of a mating connector pair. A common use case being the connection of accessory cards such as graphics accelerators to computer motherboards in desktop PC applications, they offer a relatively low-cost, high density interconnect option for applications where durability is not a primary concern.

Screen Default Ranking Price By Date

Select products	Mfr	Description	Package	Supplier Device Package	Mounting Type	Series	Operating Temperature
305-018-520-503 $6.89	EDAC Inc.	CONN EDGE DUAL FMALE 18POS 0.156	Box		Panel Mount, Through Hole	305	-40°C ~ 105°C
305-018-520-504 $5.01	EDAC Inc.	CONN EDGE DUAL FMALE 18POS 0.156	Box		Panel Mount, Through Hole	305	-40°C ~ 105°C
305-018-520-507 $6.89	EDAC Inc.	CONN EDGE DUAL FMALE 18POS 0.156	Box		Panel Mount, Through Hole	305	-40°C ~ 105°C
305-018-520-508 $6.89	EDAC Inc.	CONN EDGE DUAL FMALE 18POS 0.156	Box		Panel Mount, Through Hole	305	-40°C ~ 105°C
305-018-520-512 $6.19	EDAC Inc.	CONN EDGE DUAL FMALE 18POS 0.156	Bulk		Panel Mount, Through Hole	305	-40°C ~ 105°C
305-018-520-558 $7.54	EDAC Inc.	CONN EDGE DUAL FMALE 18POS 0.156	Box		Panel Mount, Through Hole	305	-40°C ~ 105°C
305-018-520-568 $7.54	EDAC Inc.	CONN EDGE DUAL FMALE 18POS 0.156	Box		Panel Mount, Through Hole	305	-40°C ~ 105°C
305-018-520-578 $7.54	EDAC Inc.	CONN EDGE DUAL FMALE 18POS 0.156	Box		Panel Mount, Through Hole	305	-40°C ~ 105°C
