Edgeboard Connectors

Card edge or edgeboard connectors are a style of connector system in which (typically) a pattern of exposed copper regions at the periphery of a printed circuit board constitutes one-half of a mating connector pair. A common use case being the connection of accessory cards such as graphics accelerators to computer motherboards in desktop PC applications, they offer a relatively low-cost, high density interconnect option for applications where durability is not a primary concern.

Screen Default Ranking Price By Date

Select products	Mfr	Description	Package	Supplier Device Package	Mounting Type	Series	Operating Temperature
2199119-6 $1.14	TE Connectivity AMP Connectors	CONN M.2 FMALE 67POS 0.020 GOLD	Tape & Reel (TR)		Surface Mount, Right Angle	-	-40°C ~ 80°C
2199119-7 $0.70	TE Connectivity AMP Connectors	CONN M.2 FMALE 67POS 0.020 GOLD	Tape & Reel (TR)		Surface Mount, Right Angle	-	-40°C ~ 80°C
2199119-8 $1.60	TE Connectivity AMP Connectors	CONN M.2 FMALE 67POS 0.020 GOLD	Tape & Reel (TR),Cut Tape (CT)		Surface Mount, Right Angle	-	-40°C ~ 80°C
2199119-9 $0.95	TE Connectivity AMP Connectors	CONN M.2 FMALE 67POS 0.020 GOLD	Tape & Reel (TR)		Surface Mount, Right Angle	-	-40°C ~ 80°C
2199125-1	TE Connectivity AMP Connectors	CONN M.2 FMALE 67POS 0.020 GOLD	Tape & Reel (TR)		Surface Mount, Right Angle	-	-
2199125-2	TE Connectivity AMP Connectors	CONN M.2 FMALE 67POS 0.020 GOLD	Tape & Reel (TR)		Surface Mount, Right Angle	-	-
2199125-3 $0.95	TE Connectivity AMP Connectors	CONN M.2 FMALE 67POS 0.020 GOLD	Tape & Reel (TR)		Surface Mount, Right Angle	-	-
2199125-4 $0.95	TE Connectivity AMP Connectors	CONN M.2 FMALE 67POS 0.020 GOLD	Tape & Reel (TR)		Surface Mount, Right Angle	-	-
