Edgeboard Connectors

Card edge or edgeboard connectors are a style of connector system in which (typically) a pattern of exposed copper regions at the periphery of a printed circuit board constitutes one-half of a mating connector pair. A common use case being the connection of accessory cards such as graphics accelerators to computer motherboards in desktop PC applications, they offer a relatively low-cost, high density interconnect option for applications where durability is not a primary concern.

Screen Default Ranking Price By Date

Select products	Mfr	Description	Package	Supplier Device Package	Mounting Type	Series	Operating Temperature
3-6437275-6 $3.92	TE Connectivity AMP Connectors	CONN EDGE DUAL FMALE 20POS 0.100	Bulk		Through Hole	-	-55°C ~ 125°C
3-6437275-9 $3.92	TE Connectivity AMP Connectors	CONN EDGE DUAL FMALE 20POS 0.100	Bulk		Through Hole	-	-55°C ~ 125°C
301-120-520-201 $2.29	EDAC Inc.	CONN EDGE DUAL FML 120POS 0.050	Bulk		Through Hole	301	-55°C ~ 85°C
301-184-520-201 $8.42	EDAC Inc.	CONN EDGE DUAL FML 184POS 0.050	Bulk		Through Hole	301	-55°C ~ 85°C
302-004-221-201 $1.97	EDAC Inc.	302 SERIES (.05" (1.27MM) CONTAC	Tube		Through Hole	302	-55°C ~ 85°C
302-004-256-201 $2.89	EDAC Inc.	302 SERIES (.05" (1.27MM) CONTAC	Tube		Board Edge, Straddle Mount	302	-55°C ~ 85°C
302-004-258-201 $2.89	EDAC Inc.	302 SERIES (.05" (1.27MM) CONTAC	Tube		Through Hole, Right Angle	302	-55°C ~ 85°C
302-004-321-201 $1.88	EDAC Inc.	302 SERIES (.05" (1.27MM) CONTAC	Tube		Through Hole	302	-55°C ~ 85°C
