Edgeboard Connectors

Card edge or edgeboard connectors are a style of connector system in which (typically) a pattern of exposed copper regions at the periphery of a printed circuit board constitutes one-half of a mating connector pair. A common use case being the connection of accessory cards such as graphics accelerators to computer motherboards in desktop PC applications, they offer a relatively low-cost, high density interconnect option for applications where durability is not a primary concern.

Screen Default Ranking Price By Date

Select products	Mfr	Description	Package	Supplier Device Package	Mounting Type	Series	Operating Temperature
305-064-556-503 $13.42	EDAC Inc.	CONN EDGE DUAL FMALE 64POS 0.156	Box		Board Edge, Straddle Mount	305	-40°C ~ 105°C
305-064-556-504 $11.66	EDAC Inc.	CONN EDGE DUAL FMALE 64POS 0.156	Box		Board Edge, Straddle Mount	305	-40°C ~ 105°C
305-064-556-507 $13.42	EDAC Inc.	CONN EDGE DUAL FMALE 64POS 0.156	Box		Board Edge, Straddle Mount	305	-40°C ~ 105°C
305-064-556-508 $13.42	EDAC Inc.	CONN EDGE DUAL FMALE 64POS 0.156	Box		Board Edge, Straddle Mount	305	-40°C ~ 105°C
305-064-556-512 $12.76	EDAC Inc.	CONN EDGE DUAL FMALE 64POS 0.156	Bulk		Board Edge, Straddle Mount	305	-40°C ~ 105°C
305-064-556-558 $14.04	EDAC Inc.	CONN EDGE DUAL FMALE 64POS 0.156	Box		Board Edge, Straddle Mount	305	-40°C ~ 105°C
305-064-556-568 $14.04	EDAC Inc.	CONN EDGE DUAL FMALE 64POS 0.156	Box		Board Edge, Straddle Mount	305	-40°C ~ 105°C
305-064-556-578 $14.04	EDAC Inc.	CONN EDGE DUAL FMALE 64POS 0.156	Box		Board Edge, Straddle Mount	305	-40°C ~ 105°C
