Edgeboard Connectors

Card edge or edgeboard connectors are a style of connector system in which (typically) a pattern of exposed copper regions at the periphery of a printed circuit board constitutes one-half of a mating connector pair. A common use case being the connection of accessory cards such as graphics accelerators to computer motherboards in desktop PC applications, they offer a relatively low-cost, high density interconnect option for applications where durability is not a primary concern.

Screen Default Ranking Price By Date

Select products	Mfr	Description	Package	Supplier Device Package	Mounting Type	Series	Operating Temperature
305-018-500-201 $5.01	EDAC Inc.	CONN EDGE DUAL FMALE 18POS 0.156	Box		Free Hanging (In-Line)	305	-40°C ~ 105°C
305-018-500-202 $5.01	EDAC Inc.	CONN EDGE DUAL FMALE 18POS 0.156	Box		Panel Mount	305	-40°C ~ 105°C
305-018-500-203 $6.89	EDAC Inc.	CONN EDGE DUAL FMALE 18POS 0.156	Box		Panel Mount	305	-40°C ~ 105°C
305-018-500-204 $5.01	EDAC Inc.	CONN EDGE DUAL FMALE 18POS 0.156	Box		Panel Mount	305	-40°C ~ 105°C
305-018-500-207 $6.89	EDAC Inc.	CONN EDGE DUAL FMALE 18POS 0.156	Box		Panel Mount	305	-40°C ~ 105°C
305-018-500-208 $6.89	EDAC Inc.	CONN EDGE DUAL FMALE 18POS 0.156	Box		Panel Mount	305	-40°C ~ 105°C
305-018-500-212 $6.19	EDAC Inc.	CONN EDGE DUAL FMALE 18POS 0.156	Bulk		Panel Mount	305	-40°C ~ 105°C
305-018-500-258 $7.54	EDAC Inc.	CONN EDGE DUAL FMALE 18POS 0.156	Box		Panel Mount	305	-40°C ~ 105°C
