Headers, Male Pins

This type of header contains male pins within a plastic base and is meant to be mated with a rectangular cable connector or a female socket header for board-to-board connection. These come in a variety of position and pitch options, with some having a breakaway option to manually change position count with ease. Some are shrouded with 1 to 4 walls or unshrouded. Mounting types include panel mount, board edge, stacking, surface mount, and through-hole.

Screen Default Ranking Price By Date

Select products	Mfr	Description	Package	Supplier Device Package	Mounting Type	Series	Operating Temperature
1-794625-0 $1.51	TE Connectivity AMP Connectors	CONN HEADER SMD R/A 10POS 3MM	Bulk		Surface Mount, Right Angle	Micro MATE-N-LOK	-40°C ~ 105°C
1-794626-2 $1.97	TE Connectivity AMP Connectors	CONN HEADER SMD R/A 12POS 3MM	Bulk		Surface Mount, Right Angle	Micro MATE-N-LOK	-40°C ~ 105°C
1-794627-2 $1.50	TE Connectivity AMP Connectors	CONN HEADER SMD R/A 12POS 3MM	Tape & Reel (TR)		Surface Mount, Right Angle	Micro MATE-N-LOK	-40°C ~ 105°C
1-794627-4 $3.63	TE Connectivity AMP Connectors	CONN HEADER SMD R/A 14POS 3MM	Tape & Reel (TR),Cut Tape (CT)		Surface Mount, Right Angle	Micro MATE-N-LOK	-40°C ~ 105°C
1-794627-6 $3.13	TE Connectivity AMP Connectors	CONN HEADER SMD R/A 16POS 3MM	Tape & Reel (TR),Cut Tape (CT)		Surface Mount, Right Angle	Micro MATE-N-LOK	-40°C ~ 105°C
1-794627-8 $2.04	TE Connectivity AMP Connectors	CONN HEADER SMD R/A 18POS 3MM	Tape & Reel (TR)		Surface Mount, Right Angle	Micro MATE-N-LOK	-40°C ~ 105°C
1-794628-2 $1.67	TE Connectivity AMP Connectors	CONN HEADER SMD R/A 12POS 3MM	Bulk		Surface Mount, Right Angle	Micro MATE-N-LOK	-40°C ~ 105°C
1-794629-0 $1.92	TE Connectivity AMP Connectors	CONN HEADER SMD R/A 10POS 3MM	Tape & Reel (TR)		Surface Mount, Right Angle	Micro MATE-N-LOK	-40°C ~ 105°C
