Edgeboard Connectors

Card edge or edgeboard connectors are a style of connector system in which (typically) a pattern of exposed copper regions at the periphery of a printed circuit board constitutes one-half of a mating connector pair. A common use case being the connection of accessory cards such as graphics accelerators to computer motherboards in desktop PC applications, they offer a relatively low-cost, high density interconnect option for applications where durability is not a primary concern.

Screen Default Ranking Price By Date

Select products	Mfr	Description	Package	Supplier Device Package	Mounting Type	Series	Operating Temperature
3-2349820-3 $4.50	TE Connectivity AMP Connectors	PCIEG4,SMT,V,98P,G/F,ML,HT,OEW	Bulk,Retail Package		Surface Mount	-	-40°C ~ 85°C
3-2349820-4 $8.16	TE Connectivity AMP Connectors	PCIEG4,SMT,V,164P,G/F,ML,HT,OEW	Bulk		Surface Mount	-	-40°C ~ 85°C
3-2349820-7 $3.97	TE Connectivity AMP Connectors	CIEG4,SMT,V,98P,G/F,ML,HT,OEW	Bulk		Surface Mount	-	-
3-2349820-8 $5.78	TE Connectivity AMP Connectors	PCIEG4,SMT,V,164P,G/F,ML,HT,OEW	Bulk,Retail Package		Surface Mount	-	-40°C ~ 85°C
3-2354154-4 $7.08	TE Connectivity AMP Connectors	CONN PCI EXP FMALE 164POS 0.039	Bulk,Tray		Surface Mount	-	-40°C ~ 85°C
3-2354154-8 $5.06	TE Connectivity AMP Connectors	CONN PCI EXP FMALE 164POS 0.039	Tray		Surface Mount	-	-40°C ~ 85°C
3-2362375-1	TE Connectivity AMP Connectors	PCIE GEN4, 36POS ,G/F ,DIP ,3.1M	Tray		-	*	-
3-2362375-2 $6.24	TE Connectivity AMP Connectors	PCIE GEN4, 64POS ,G/F ,DIP ,3.1M	Tray		Through Hole	-	-40°C ~ 85°C
