IGBTs

IGBTs (Insulated Gate Bipolar Transistors) are multilayered semiconductor devices with three terminals that can handle high currents and have fast switching features. They are characterized by type, collector-emitter breakdown voltage, collector current, pulsed collector current, VCE(ON), switching energy, and gate charge.

Screen Default Ranking Price By Date

Select products	Mfr	Description	Package	Supplier Device Package	Mounting Type	Series	Operating Temperature
HGTP10N40E1 $1.00	Harris Corporation	IGBT 400V 10A TO-220-3	Bulk	TO-220-3	Through Hole	-	-55°C ~ 150°C (TJ)
HGTP10N40EID $1.34	Harris Corporation	17.5A, 400V, N-CHANNEL IGBT	Bulk	-	-	*	-
HGTP10N40F1D $0.82	Harris Corporation	IGBT 400V 12A TO-220	Bulk	TO-220	Through Hole	-	-55°C ~ 150°C (TJ)
HGTP10N50E1 $1.79	Harris Corporation	IGBT 500V 10A TO-220-3	Bulk	TO-220-3	Through Hole	-	-55°C ~ 150°C (TJ)
HGTP10N50E1D $2.67	Harris Corporation	IGBT 500V 17.5A TO-220	Bulk	TO-220	Through Hole	-	-55°C ~ 150°C (TJ)
HGTP12N6001 $1.91	Harris Corporation	HGTP12N6001	Bulk	-	-	*	-
HGTP12N60A4 $0.61	Fairchild Semiconductor	IGBT 600V 54A TO-220-3	Tube	TO-220-3	Through Hole	-	-55°C ~ 150°C (TJ)
HGTP12N60A4D $1.55	Fairchild Semiconductor	IGBT 600V 54A TO-220-3	Bulk	TO-220-3	Through Hole	-	-55°C ~ 150°C (TJ)
