IGBTs

IGBTs (Insulated Gate Bipolar Transistors) are multilayered semiconductor devices with three terminals that can handle high currents and have fast switching features. They are characterized by type, collector-emitter breakdown voltage, collector current, pulsed collector current, VCE(ON), switching energy, and gate charge.

Screen Default Ranking Price By Date

Select products	Mfr	Description	Package	Supplier Device Package	Mounting Type	Series	Operating Temperature
FGAF40N60UFTU $1.56	Fairchild Semiconductor	IGBT	Bulk	-	-	*	-
FGAF40S65AQ $1.74	onsemi	IGBT TRENCH FS 650V 80A TO-3PF-3	Tube,Tube	TO-3PF-3	Through Hole	-	-55°C ~ 175°C (TJ)
FGB20N60SF $1.53	Fairchild Semiconductor	IGBT FIELD STOP 600V 40A TO-263	Bulk	TO-263 (D2PAK)	Surface Mount	-	-55°C ~ 150°C (TJ)
FGB20N60SFD $2.15	onsemi	IGBT FIELD STOP 600V 40A TO-263	Tape & Reel (TR),Tape & Reel (TR)	TO-263 (D2PAK)	Surface Mount	-	-55°C ~ 150°C (TJ)
FGB20N60SFD-F085 $4.17	onsemi	IGBT FIELD STOP 600V 40A TO-263	Tape & Reel (TR),Cut Tape (CT)	TO-263 (D2PAK)	Surface Mount	-	-55°C ~ 150°C (TJ)
FGB20N6S2 $0.55	Fairchild Semiconductor	IGBT 600V 28A TO-263	Tube	TO-263 (D2PAK)	Surface Mount	-	-55°C ~ 150°C (TJ)
FGB3040CS $1.67	Fairchild Semiconductor	IGBT 430V 21A D2PAK-6	Bulk	D2PAK-6	Surface Mount	EcoSPARK®	-40°C ~ 175°C (TJ)
FGB3040G2-F085 $3.94	onsemi	IGBT 400V 41A TO-263	Tape & Reel (TR),Cut Tape (CT)	TO-263 (D2PAK)	Surface Mount	EcoSPARK®	-55°C ~ 175°C (TJ)
