IGBTs

IGBTs (Insulated Gate Bipolar Transistors) are multilayered semiconductor devices with three terminals that can handle high currents and have fast switching features. They are characterized by type, collector-emitter breakdown voltage, collector current, pulsed collector current, VCE(ON), switching energy, and gate charge.

Screen Default Ranking Price By Date

Select products	Mfr	Description	Package	Supplier Device Package	Mounting Type	Series	Operating Temperature
FGH20N60SFDTU-F085	onsemi	IGBT FIELD STOP 600V 40A TO247	Tube	TO-247-3	Through Hole	-	-55°C ~ 150°C (TJ)
FGH20N60UFDTU	onsemi	IGBT FIELD STOP 600V 40A TO247	Tube	TO-247-3	Through Hole	-	-55°C ~ 150°C (TJ)
FGH20N6S2D $0.70	Fairchild Semiconductor	IGBT 600V 28A TO-247	Tube	TO-247	Through Hole	-	-55°C ~ 150°C (TJ)
FGH25N120FTDS	onsemi	IGBT TRENCH FS 1200V 50A TO-247	Tube	TO-247-3	Through Hole	-	-55°C ~ 150°C (TJ)
FGH25T120SMD-F155	onsemi	IGBT TRENCH FS 1200V 50A TO-247	Tube	TO-247-3	Through Hole	-	-55°C ~ 175°C (TJ)
FGH30N120FTDTU $2.34	onsemi	IGBT TRENCH FS 1200V 60A TO-247	Tube	TO-247-3	Through Hole	-	-55°C ~ 150°C (TJ)
FGH30N60LSDTU $9.64	onsemi	IGBT 600V 60A TO-247-3	Tube,Tube	TO-247-3	Through Hole	-	-55°C ~ 150°C (TJ)
FGH30N6S2 $0.88	Fairchild Semiconductor	IGBT 600V 45A TO-247	Tube	TO-247	Through Hole	-	-55°C ~ 150°C (TJ)
